PurposeCommand or Action
A PIM device can be an RP for more than one group. Only one RP address can
be used at a time within a PIM domain. The access list conditions specify for
which groups the device is an RP.
10.1.1.1 20 override
•
For ip-address, enter the unicast address of the RP in dotted-decimal
notation.
•
(Optional) For access-list-number, enter an IP standard access list number
from 1 to 99. If no access list is configured, the RP is used for all groups.
•
(Optional) The override keyword indicates that if there is a conflict
between the RP configured with this command and one learned by Auto-RP
or BSR, the RP configured with this command prevails.
To remove an RP address, use the no ip pim rp-address ip-address
[access-list-number] [override] global configuration command.
Note
Creates a standard access list, repeating the command as many times as
necessary.
access-list access-list-number {deny |
permit} source [source-wildcard]
Step 3
Example:
Switch(config)# access-list 25
•
For access-list-number, enter the access list number specified in Step 2.
•
The deny keyword denies access if the conditions are matched.
permit 10.5.0.1 255.224.0.0
•
The permit keyword permits access if the conditions are matched.
•
For source, enter the multicast group address for which the RP should be
used.
•
(Optional) For source-wildcard, enter the wildcard bits in dotted decimal
notation to be applied to the source. Place ones in the bit positions that
you want to ignore.
The access list is always terminated by an implicit deny statement for everything.
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 4
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 5
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config
Step 6
startup-config
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29426-01 49
Configuring PIM
Configuring a Rendezvous Point

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
