Table 13: Commands for Monitoring IP Multicast Routing
PurposeCommand
Queries a multicast router or multilayer
switch about which neighboring multicast
devices are peering with it.
mrinfo [hostname | address] [source-address | interface]
mrinfo { [hostname | address] | vrf }
Displays IP multicast packet rate and loss
information.
mstat source [destination] [group]
mstat { [hostname | address] | vrf }
Traces the path from a source to a
destination branch for a multicast
distribution tree for a given group.
mtrace source [destination] [group]
mtrace { [hostname | address] | vrf }
Configuration Examples for IP Multicast Routing
Example: Configuring an IP Multicast Boundary
This example shows how to set up a boundary for all administratively-scoped addresses:
Switch(config)# access-list 1 deny 239.0.0.0 0.255.255.255
Switch(config)# access-list 1 permit 224.0.0.0 15.255.255.255
Switch(config)# interface gigabitethernet1/0/1
Switch(config-if)# ip multicast boundary 1
Related Topics
Configuring an IP Multicast Boundary, on page 98
Where to Go Next
You can configure the following for your IP multicast configuration:
•
IGMP feature support
•
CGMP feature support
•
PIM feature support
•
SSM feature support
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29426-01 103
Configuring IP Multicast Routing
Configuration Examples for IP Multicast Routing

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
