Cisco Catalyst 2960-XR Configuration Guides

PurposeCommand or Action
Returns to privileged EXEC mode.end
Step 5
Example:
Switch(config-if)# end
Verifies your entries.show running-config
Step 6
Example:
Switch# show running-config
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Step 7
Example:
Switch# copy running-config startup-config
Configuring Candidate BSRs
You can configure one or more candidate BSRs. The devices serving as candidate BSRs should have good
connectivity to other devices and be in the backbone portion of the network.
This procedure is optional.
SUMMARY STEPS
1.
configure terminal
2.
ip pim bsr-candidate interface-id hash-mask-length [priority]
3.
end
4.
show running-config
5.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29426-01 61
Configuring PIM
Configuring PIMv2 BSR

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
