They are sent by the designated router that is directly connected to a source and are received by the RP for
the group.
Multiple sources sending to groups use the shared tree.
You can configure the PIM device to stay on the shared tree. You can configure the PIM device to stay on
the shared tree. For more information, see Delaying the Use of PIM Shortest-Path Tree, on page 66.
Related Topics
Delaying the Use of PIM Shortest-Path Tree, on page 66
Default PIM Routing Configuration
This table displays the default PIM routing configuration for the switch.
Table 7: Default Multicast Routing Configuration
Default SettingFeature
Disabled on all interfaces.Multicast routing
Version 2.PIM version
No mode is defined.PIM mode
None configured.PIM stub routing
None configured.PIM RP address
Disabled.PIM domain border
None.PIM multicast boundary
Disabled.Candidate BSRs
Disabled.Candidate RPs
0 kb/s.Shortest-path tree threshold rate
30 seconds.PIM router query message interval
How to Configure PIM
Enabling PIM Stub Routing
This procedure is optional.
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29426-01 45
Configuring PIM
Default PIM Routing Configuration

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
