Cisco Catalyst 2960-XR Configuration Guides

Default SettingFeature
Disabled.Candidate RPs
0 kb/s.Shortest-path tree threshold rate
30 seconds.PIM router query message interval
How to Configure Basic IP Multicast Routing
Configuring Basic IP Multicast Routing
By default, multicast routing is disabled, and there is no default mode setting.
This procedure is required.
SUMMARY STEPS
1.
configure terminal
2.
ip multicast-routing distributed
3.
interface interface-id
4.
ip pim version [1 | 2]
5.
ip pim {dense-mode | sparse-mode | sparse-dense-mode}
6.
end
7.
show running-config
8.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Enables IP multicast distributed switchingip multicast-routing distributed
Step 2
Example:
Switch(config)# ip
To disable multicasting, use the no ip multicast-routing
distributed global configuration command.
Note
multicast-routing distributed
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
96 OL-29426-01
Configuring IP Multicast Routing
How to Configure Basic IP Multicast Routing

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
