Usage Guidelines
The vrf keyword is valid only for out-of-band VRF configurations.
Task ID
OperationsTask ID
readsystem
Examples
The following sample output displays all the interfaces that are configured as inband or out-of-band interfaces
under MPP:
RP/0/RP0/CPU0:router# show mgmt-plane
Management Plane Protection
inband interfaces
----------------------
interface - GigabitEthernet0_1_1_0
ssh configured -
All peers allowed
telnet configured -
peer v4 allowed - 10.1.0.0/16
all configured -
All peers allowed
interface - GigabitEthernet0_1_1_0
telnet configured -
peer v4 allowed - 10.1.0.0/16
interface - all
all configured -
All peers allowed
outband interfaces
----------------------
interface - GigabitEthernet0_1_1_0
tftp configured -
peer v6 allowed - 33::33
The following sample output displays the Virtual Private Network (VPN) routing and forwarding (VRF)
reference of an out-of-band interface:
RP/0/RP0/CPU0:router# show mgmt-plane out-of-band vrf
Management Plane Protection -
out-of-band VRF - my_out_of_band
Related Commands
DescriptionCommand
Configures management plane protection to allow
and disallow protocols.
management-plane, on page 174
Cisco IOS XR System Security Command Reference for the Cisco CRS Router, Release 4.1
178 OL-24740-01
Management Plane Protection Commands
show mgmt-plane
