4-54 D9865 Satellite Receiver Installation and Operation Guide 4035197 Rev C
Configuring IP Setup, Continued
Setting the Filter Mode
The filter mode sets the multicast forwarding for MPE data output.
Proceed as follows to set up the filter mode:
1. From the Advanced Setup screen, select IP Setup and press OK.
2. The Filter Mode sets whether all the MPE data is forwarded (Forward All). It
can forward up to 5 PIDs at the maximum bit rates shown in the following table.
Otherwise, select Forward None.
3. Set the MPE Optimization setting. Select High Bitrate (default) to accumulate
the IP packets before they are processed in short bursts, increasing the allowable
bit rate of MPE data. Select Low Jitter to emit the IP packets in a constant
stream, resulting in low latency.
MPE Bit Rate No
Decoding
5 Mbps SD
Video Decoded
20 Mbps HD
Video Decoded
Multicast 30 Mbps 20 Mbps 15 Mbps
Unicast 20 Mbps 15 Mbps 10 Mbps
