1
Enter the global configuration mode and configure the interface.
RP/0/RP0/CPU0:router# configure
RP/0/RP0/CPU0:router(config)# interface TenGigE0/0/0/8
2
Configure Frequency Synchronization on this interface.
RP/0/RP0/CPU0:router(config-if)# frequency synchronization
By default, frequency signal chosen by the system is used for clocking transmission. However, this does
not enable the use of the interface as an input.
Note
3
Configure the interface to be used as a timing source by the selection algorithm.
RP/0/RP0/CPU0:router(config-if-freqsync)# selection input
4
Configure priority of the frequency source on a controller or an interface by specifying a value in the range
1 (highest priority) to 254 (lowest priority). The default value is 100. The priority value set is used by the
clock-selection algorithm to choose between two sources that have the same quality level (QL) and lower
priority values are usually preferred.
RP/0/RP0/CPU0:router(config-if-freqsync)# priority 101
5
Configure the time (in minutes) to wait after the interface is up, before it can be used for frequency
synchronization by specifying a value in the range 0 to 12. The default value is 5.
RP/0/RP0/CPU0:router(config-if-freqsync)# wait-to-restore 300
6
Disable the Synchronization Status Messages (SSMs) on the interface to stop sending the packets and
ignore the received packets. For SyncE interfaces. sending or receiving ESMC packets is disabled.
RP/0/RP0/CPU0:router(config-if-freqsync)# ssm disable
7
Adjust the QL transmitted by specifying one of the following quality transmit options:
•
exact: Exact QL to be sent. DNU is sent if the exact ql value is not specified.
•
highest: Upper limit on the QL to be sent. QL value specified here is sent, if the QL value of the
selected source is higher than the QL value specified here.
•
lowest: Lower limit on the QL to be sent. DNU is sent, if the QL value of the selected source is lesser
than the QL value specified here.
RP/0/RP0/CPU0:router(config-if-freqsync)# quality transmit highest itu-t option 1 PRC
8
Adjust the QL received by specifying one of the following quality receive options before the value can
be used in the selection algorithm:
•
exact: Exact QL received unless the received value is DNU.
•
highest: Upper limit on the received QL. QL value specified here is used, if the received QL value
is higher than the QL value specified here.
•
lowest: Lower limit on the received QL. DNU is used, if the received QL value is lesser than the QL
value specified here.
RP/0/RP0/CPU0:router(config-if-freqsync)# quality receive highest itu-t option 1 PRC
System Management Configuration Guide for Cisco NCS 5000 Series Routers, IOS XR Release 6.2.x
175
Frequency Synchronization
Configuring Frequency Synchronization on an Interface
