The quality option configured here must match the globally configured quality option specified in the
quality itu-t option command.
Note
9
Exit to the global configuration mode and commit your configuration.
RP/0/RP0/CPU0:router(config-if-freqsync)# commit
Verification
To verify the configured interfaces, use show frequency synchronization interfaces command.
RP/0/RP0/CPU0:router# show frequency synchronization interfaces tenGigE 0/0/0/8
Fri Apr 7 15:06:24.123 UTC
Interface TenGigE0/0/0/8 (down)
Assigned as input for selection
Wait-to-restore time 0 minutes
SSM Enabled
Input:
Down
Last received QL: Failed
Effective QL: Failed, Priority: 100
Supports frequency
Output:
Selected source: Internal0 [0/RP0/CPU0]
Selected source QL: Opt-II,1/ST3
Effective QL: Opt-II,1/ST3
Next selection points: NCS5K_ETH_RXMUX
To verify the configurations on all line interfaces with frequency synchronization, use show frequency
synchronization interfaces brief command.
RP/0/RP0/CPU0:router# show frequency synchronization interfaces brief
Flags: > - Up D - Down S - Assigned for selection
d - SSM Disabled x - Peer timed out i - Init state
Fl Interface QLrcv QLuse Pri QLsnt Source
=== ==================== ===== ===== === ===== ================
>Sx GigabitEthernet0/2/0/0 Fail Fail 100 DNU None
Dd GigabitEthernet0/2/0/1 n/a Fail 100 n/a None
Sources configured as inputs is indicated by S in the Flags column.
Internal oscillators are always eligible as inputs.Note
To verify each configured interface separately, use show frequency synchronization interfaces node-id
command.
RP/0/RP0/CPU0:router# show frequency synchronization interfaces TenGigE0/0/0/8
Interface TenGigE0/0/0/8 (shutdown)
Assigned as input for selection
SSM Enabled
Input:
Down
Last received QL: Failed
Effective QL: Failed, Priority: 100
Output:
Selected source: Internal0 [0/RP0/CPU0]
Selected source QL: Opt-II,1/ST3
System Management Configuration Guide for Cisco NCS 5000 Series Routers, IOS XR Release 6.2.x
176
Frequency Synchronization
Configuring Frequency Synchronization on an Interface
