Cisco RV130 Administration Guide

Configuring VPN
Configuring Site-to-Site IPsec VPN Advanced Parameters
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 102
6
c. In the Pre-Shared Key field, enter the key or password. Ensure that the
password does not contain double-quotes (“).
d. In the Diffie-Hellman (DH) Group field, specify the DH Group algorithm used
when exchanging a pre-shared key. The DH Group sets the strength of the
algorithm in bits. Ensure that the DH Group is configured identically on both
sides of the IKE policy.
e. In the SA-Lifetime field, enter the interval, in seconds, after which the Security
Association becomes invalid.
f. To enable the Dead Peer Detection feature, check the Enable box. Dead Peer
Detection (DPD) is used to detect if the peer is alive. If the peer is detected as
dead, the device deletes the IPsec and IKE Security Association. If you enable
this feature, also enter these settings:
- DPD Delay—The interval, in seconds, between consecutive DPD R-U-
THERE messages. DPD R-U-THERE messages are sent only when the
IPsec traffic is idle.
- DPD Timeout—The maximum time that the device should wait to
receive a response to the DPD message before considering the peer to
be dead.
STEP 6 Click Save.
NOTE If you have a VPN connection already configured, you cannot add another without
deleting the existing VPN connection.
Managing VPN Policies
NOTE Before you create an Auto VPN Policy, ensure that you create the IKE policy based
on which you want to create the auto VPN policy.
To manage VPN policies:
STEP 1 Choose VPN > Site-to-Site IPsec VPN > Advanced VPN Setup. Click Add Row.
STEP 2 In the Add / Edit VPN Policy Configuration section:
a. In the Policy Name field, enter a unique name to identify the policy.
b. In the Policy Type field, choose one of the following options:
