Cisco RV130 Administration Guide

Configuring Quality of Service (QoS)
Configuring QoS Port-Based Settings
Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 113
7
Configuring QoS Port-Based Settings
You can configure QoS settings for every port on your device. The supports four
priority queues that allow traffic prioritization for each port.
To configure QoS settings for the ports on your device:
STEP 1 Choose QoS > QoS Port-Based Settings.
STEP 2 For each port in the QoS Port-Based Settings table, enter this information:
STEP 3 Click Save.
To restore the default port-based QoS settings, click Restore Default and save
your changes.
Trust Mode Choose one of the following options from the drop-
down menu:
• Port—Enables port-based QoS settings.
You can then set the traffic priority for a
particular port. The traffic queue priority
starts at the lowest priority of 1 and ends
with the highest priority of 3.
• DSCP—Differentiated Services Code Point
(DSCP). Enabling this feature prioritizes the
network traffic across the LAN based on the
DSCP queue mapping on the DSCP
Settings page.
• CoS—Class of service (CoS).
Default Traffic
Forwarding Queue for
Untrusted Devices
Choose a priority level for outbound traffic (1 to 3).

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
