Cisco RV130 Administration Guide

Configuring Networking
Configuring LAN Settings
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 34
3
Viewing DHCP Leased Clients
You can view a list of endpoints on the network (identified by hostname, IP
address, or MAC address) and see the IP addresses assigned to them by the
DHCP server. The VLAN of the endpoints is also displayed.
To view the DHCP clients, choose Networking > LAN > DHCP Leased Client.
For every VLAN defined on the device, a table displays a list of the clients
associated with the VLAN.
To assign a static IP address to one of the connected devices:
STEP 1 In the row of the connected device, check Add to Static DHCP.
STEP 2 Click Save.
The DHCP server on the device always assigns the IP address shown when the
device requests an IP address.
Configuring a DMZ Host
Your device supports demilitarized zones (DMZ). A DMZ is a subnetwork that is
open to the public but behind the firewall. A DMZ allows you to redirect packets
going to your WAN port IP address to a particular IP address in your LAN.
We recommended that you place hosts that must be exposed to the WAN (such as
web or e-mail servers) in the DMZ network. You can configure firewall rules to
allow access to specific services and ports in the DMZ from both the LAN or WAN.
In the event of an attack on any of the DMZ nodes, the LAN is not necessarily
vulnerable.
You must configure a fixed (static) IP address for the endpoint that you designate
as the DMZ host. You should assign the DMZ host an IP address in the same
subnet as the device LAN IP address, but it cannot be identical to the IP address
given to the LAN interface of this gateway.
To configure DMZ:
STEP 1 Choose Networking > LAN > DMZ Host.
STEP 2 Check Enable to enable DMZ on the network.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
