Cisco RV130 Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 55
3
STEP 3 Click Save.
Configuring Advertisement Prefixes
To configure the RADVD available prefixes:
STEP 1 Choose Networking > IPv6 > Advertisement Prefixes.
STEP 2 Click Add Row.
STEP 3 Enter this information:
MTU MTU size (0 or 1280 to 1500). The default is 1500
bytes.
The maximum transmission unit (MTU) is the size of
the largest packet that can be sent over the
network. The MTU is used in RAs to ensure all
nodes on the network use the same MTU value
when the LAN MTU is not well-known.
Router Life Time Router lifetime value or the time in seconds that the
advertisement messages exists on the route. The
default is 3600 seconds.
IPv6 Prefix Type Choose one of the following types:
6to4—Allows IPv6 packets to be transmitted over
an IPv4 network. It is used when an end user wants
to connect to the IPv6 Internet using their existing
IPv4 connection
Global/Local—A locally unique IPv6 address that
you can use in private IPv6 networks or a globally
unique IPv6 Internet address.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
