Cisco RV130 Administration Guide

Configuring Networking
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 19
3
STEP 5 Click Save.
Configuring PPTP
To configure the PPTP settings:
STEP 1 Choose Networking > WAN.
STEP 2 From the Internet Connection Type drop-down menu, choose PPTP.
STEP 3 Enter this information:
Authentication Type Auto-negotiation—The server sends a
configuration request specifying the security
algorithm set on it. The device then sends back
authentication credentials with the security type
sent by the server.
PAP—Password Authentication Protocol (PAP)
used by Point-to-Point Protocol to connect to the
ISP.
CHAP—Challenge Handshake Authentication
Protocol (CHAP) requires that both the client and
server know the plaintext of the secret to use ISP
services.
MS-CHAP or MS-CHAPv2—The Microsoft
version of CHAP used to access ISP services.
Internet IP Address IP address of the WAN port.
Subnet mask Subnet mask of the WAN port.
Default Gateway IP address of the default gateway.
PPTP Server IP address of the Point-To-Point Tunneling Protocol
server.
Username The username assigned to you by the ISP.
Password The password assigned to you by the ISP.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
