Cisco RV130 Administration Guide

Configuring Wireless Networks
Configuring WDS
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 75
4
Ensure that the content in the CSV file is arranged as shown in the following
example:
To import a list of authorized APs:
STEP 1 Click Merge to add the list of access points that you want to import, to the access
points displayed in Authorized AP Table. Click Replace to replace the APs in the
table with the APs in the list that you want to import.
STEP 2 Click Browse to locate the file that you want to import.
STEP 3 Click Save.
Configuring WDS
A Wireless Distribution System (WDS) is a system that enables the wireless
interconnection of access points in a network. It allows a wireless network to be
expanded using multiple access points without the need for a wired backbone to
link them.
To establish a WDS link, the device and other remote WDS peers must be
configured in the same wireless network mode, wireless channel, wireless band
selection, and encryption types (None or WEP).
Encryption • 2 — TKIP
• 4 — CCMP
Authentication • 2 — PSK
• 1 — RADIUS
Field Values
BSSID Security Encryption Authentication Wireless
Network
Channel SSID
00:1C:10:CE:44:48 4 2 2 3 1 Auth_Guest

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
