Cisco RV130 Administration Guide

Configuring Networking
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 21
3
STEP 4 Click Save.
Configuring L2TP
To configure L2TP settings:
STEP 1 Choose Networking > WAN.
STEP 2 From the Internet Connection Type drop-down menu, choose L2TP.
STEP 3 Enter this information:
DNS Server Source The DNS server address. If you already have DNS
server addresses from your ISP, choose Use these
DNS Servers, and enter the primary and secondary
addresses in the Static DNS 1 and Static DNS 2
fields.
To get DNS server addresses from your ISP,
choose Get Dynamically from ISP.
To use the DNS servers provided by OpenDNS
(208.67.222.222, 208.67.220.220) to resolve your
web addresses, choose Use OpenDNS.
Internet IP Address The IP address of the WAN port.
Subnet mask The subnet mask of the WAN port.
Default Gateway The IP address of the default gateway.
L2TP Server The IP address of the L2TP server.
Version The L2TP version that you want to use. If you select
version 3, enter the vendor ID, and the virtual circuit
ID.
Cookie Length The size of the cookie in the L2TP v3 data packet,
which identifies the L2TP session.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
