Configuring Networking
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 22
3
Vendor ID The vendor ID contained in the AVP encoding
format for L2TP.
To use the IETF-adopted attribute values in the AVP,
select Standard.
To implement Cisco’s L2TP extensions and private
attribute values, select Cisco.
Virtual Circuit ID The identifier for the Layer 2 circuit over which
L2TP data packets are carried. This information is
required if you selected Cisco as the Vendor ID for
L2TP v3.
Username Enter your username assigned to you by the ISP.
Password Enter your password assigned to you by the ISP.
Connect on Demand Select this option if your ISP charges based on the
amount of time that you are connected. When you
select this option, the Internet connection is on only
when traffic is present. If the connection is idle—
that is, no traffic is flowing—the connection is
closed. If you click Connect on Demand, enter the
number of minutes after which the connection
shuts off in the Max Idle Time field.
Keep Alive When you select this option, the Internet
connection is always on. In the redial period field,
enter the number of seconds after which the
device attempts to reconnect if it is disconnected.
Authentication Type Auto-negotiation—The server sends a
configuration request specifying the security
algorithm set on it. The device then sends back
authentication credentials with the security type
sent by the server.
PAP—Password Authentication Protocol (PAP) is
used to connect to the ISP.
CHAP—Challenge Handshake Authentication
Protocol (CHAP) is used to connect to the ISP.
MS-CHAP or MS-CHAPv2—Microsoft Challenge
Handshake Authentication Protocol is used to
connect to the ISP.
