Cisco RV130 Administration Guide

Configuring Networking
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 24
3
STEP 2 Click Save.
Untagged VLAN Check the box to enable VLAN tagging. When
enabled (the default), all traffic is tagged with a
VLAN ID.
By default, all traffic on the device uses VLAN 1, the
default untagged VLAN. All traffic is untagged until
you disable the untagged VLAN, change the
untagged traffic VLAN ID, or change the VLAN ID.
Untagged VLAN ID A number between 1 and 4094 for the untagged
VLAN ID. The default is 1. Traffic on the VLAN that
you specify in this field is not tagged with a VLAN
ID when forwarded to the network.
VLAN 1 is the default untagged VLAN.
AP Management VLAN The VLAN associated with the IP address you use
to access the device when it is configured as an
access point.
If you create additional VLANs, for security
reasons, choose a value that corresponds with the
VLAN configured on other switches in the network.
You may need to change the management VLAN to
limit access to Device Manager.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
