Cisco RV215W Administration Guide

Administering Your Router
Configuring Simple Network Management (SNMP)
Cisco RV215W Wireless-N VPN Firewall Administration Guide 127
11
STEP 3 Click Save.
Configuring the SNMP Traps
The fields in the SNMP Trap Configuration section allow you to configure an
SNMP agent to which the firewall sends trap messages (notifications).
To configure the traps:
STEP 1 Choose Administration > SNMP.
STEP 2 Under Trap Configuration, configure the following settings:
Security Level Choose the SNMPv3 security level:
No Authentication and No Privilege—Does not
require any Authentication and Privacy.
Authentication and No Privilege—Submit only
Authentication algorithm and password.
Authentication and Privilege—Submit
Authentication/privacy algorithm and password.
Authentication
Algorithm Server
Select the type of authentication algorithm (MD5 or
SHA).
Authentication
Password
Enter the authentication password.
Privacy Algorithm Choose the type of privacy algorithm (DES or AES).
Privacy Password Enter the privacy password.
IP Address Enter the IP address of the SNMP manager or trap
agent.
Port Enter the SNMP trap port of the IP address to
which the trap messages will be sent.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
