Cisco RV215W Administration Guide

Configuring Networking
Configuring the LAN Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 43
6
Viewing DHCP Leased Clients
You can view a list of endpoints on the network (identified by hostname, IP
address, or MAC address) and see the IP addresses assigned to them by the
DHCP server. The VLAN of the endpoints is also displayed.
To view the DHCP clients, choose Networking > LAN > DHCP Leased Clients.
For every VLAN defined on the device, a table displays a list of the clients
associated with the VLAN.
To assign a static IP address to one of the connected devices:
STEP 1 In the row of the connected device, check Add to Static DHCP.
STEP 2 Click Save.
The DHCP server on the device always assigns the IP address shown when the
device requests an IP address.
Configuring a DMZ Host
The device supports demilitarized zones (DMZ). A DMZ is a subnetwork that is
open to the public but behind the firewall. A DMZ allows you to redirect packets
going to your WAN port IP address to a particular IP address in your LAN.
We recommended that you place hosts that must be exposed to the WAN (such as
web or e-mail servers) in the DMZ network. You can configure firewall rules to
allow access to specific services and ports in the DMZ from both the LAN or WAN.
In the event of an attack on any of the DMZ nodes, the LAN is not necessarily
vulnerable.
You must configure a fixed (static) IP address for the endpoint that you designate
as the DMZ host. You should assign the DMZ host an IP address in the same
subnet as the device LAN IP address, but it cannot be identical to the IP address
given to the LAN interface of this gateway.
To configure DMZ:
STEP 1 Choose Networking > LAN > DMZ Host.
STEP 2 Check Enable to enable DMZ on the network.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
