Page #28 background imageLoading...
Page #28 background image
Configuring Networking
Configuring the WAN Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 28
6
STEP 4 Click Save.
Configuring PPPoE
To configure the Point-to-Point Protocol over Ethernet (PPPoE) settings:
STEP 1 Choose Networking > WAN.
STEP 2 From the Internet Connection Type drop-down menu, choose PPPoE.
STEP 3 Enter the following information (you might need to contact your ISP to obtain your
PPPoE login information):
Default Gateway IP address of the default gateway.
Static DNS 1 IP address of the primary DNS server.
Static DNS 2 IP address of the secondary DNS server.
Username The username assigned by the ISP.
Password The password assigned by the ISP.
Connect on Demand Select this option if your ISP charges based on the
amount of time that you are connected. When you
select this option, the Internet connection is on only
when traffic is present. If the connection is idle—
that is, no traffic is flowing—the connection is
closed. If you click Connect on Demand, enter the
number of minutes after which the connection
shuts off in the Max Idle Time field.
Keep Alive When you select this option, the Internet
connection is always on. In the redial period field,
enter the number of seconds after which the
device attempts to reconnect if it is disconnected.
