Cisco RV215W Administration Guide

Administering Your Router
Configuring Logging
Cisco RV215W Wireless-N VPN Firewall Administration Guide 130
11
Configuring Port Mirroring
Port mirroring monitors network traffic by sending copies of all incoming and
outgoing packets from one port to a monitoring port. You can use port mirroring as
a diagnostic or debugging tool, especially when fending off an attack or viewing
user traffic from LAN to WAN to see if users are accessing information or websites
they are not supposed to.
The LAN host (PC) should use a static IP address to avoid any issues with port
mirroring. DHCP leases can expire for a LAN host and can cause port mirroring to
fail if a static IP address is not configured for the LAN host.
To configure port mirroring:
STEP 1 Choose Administration > Diagnostics > Port Mirroring.
STEP 2 In the Mirror Source field, select the ports to mirror.
STEP 3 From the Mirror Port drop-down menu, choose a mirror port. If you use a port for
mirroring, do not use it for any other traffic.
STEP 4 Click Save.
Configuring Logging
The Cisco RV215W allows you to configure logging options.
Configuring Logging Settings
To configure logging:
STEP 1 Choose Administration > Logging > Log Settings.
STEP 2 In the Log Mode field, check Enable.
STEP 3 Click Add Row.
STEP 4 Configure the following settings:

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
