Cisco RV215W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV215W Wireless-N VPN Firewall Administration Guide 57
6
STEP 4 Click Save.
Configuring IPv6 LAN Connections
In the IPv6 mode, the LAN DHCP server is enabled by default (similar to the IPv4
mode). The DHCPv6 server assigns IPv6 addresses from configured address
pools that use the IPv6 prefix length assigned to the LAN.
To configure IPv6 LAN settings on your device, you must first set the IP mode to
one of the following modes:
• LAN:IPv6, WAN:IPv4
• LAN:IPv6, WAN:IPv6
• LAN:IPv4+IPv6, WAN:IPv4
• LAN:IPv4+IPv6, WAN:IPv4+IPv6
See Configuring the IP Mode for more information on how to set the IP mode.
To configure IPv6 LAN settings:
STEP 1 Choose Networking > IPv6 > IPv6 LAN Configuration.
STEP 2 Enter the following information to configure the IPv6 LAN address:
IPv6 Address Enter the IPv6 address of the device.
The default IPv6 address for the gateway is fec0::1
(or FEC0:0000:0000:0000:0000:0000:0000:0001).
You can change this 128-bit IPv6 address based on
your network requirements.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
