Cisco RV215W Administration Guide

Viewing the Device Status
Viewing the IPSec Connection Status
Cisco RV215W Wireless-N VPN Firewall Administration Guide 21
5
Viewing the IPSec Connection Status
The IPsec connection status shows the status of active VPN policies on the
device. (These policies are configured on the VPN > Advanced VPN Setup page.)
To view the IPsec connection status:
STEP 1 Choose Status > IPSec Connection Status. The table displays the following
information:
• Refresh Rate—Choose the rate at which you want the data display to clear
and display the newest data.
• Show Simplified Statistic Data—By default, byte data is displayed in bytes
and other numerical data is displayed in long form. To show the bytes in
kilobytes (KB) and the numerical data in rounded-up form, check Show
Simplified Statistic Data.
• Policy Name—Name of the VPN policy for which data is displayed.
• Local or Remote—Displays the local and remote IP addresses.
• Start Time and End Time—Displays the start and end times of the IPsec
connections.
• Duration—Displays the elapsed time for which the connection is or was
active.
• Packet—Displays the received (Rx) and transmitted (Tx) packets on the
connection.
• Byte—Displays the received (Rx) and transmitted (Tx) bytes on the
connection.
• State—Displays the state of the connection (for example, active or not
connected).
• Action—Displays actions you can perform on the connection (for example,
disconnect).
• Ext Action—Displays if you can switch between the primary and the
secondary VPN connections. If the Rollback enable check box on the
Advanced VPN Parameters page is checked, the Switch button is dimmed.
STEP 2 If you made any changes, click Save.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
