Cisco RV215W Administration Guide

Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 75
7
• TKIP/AES—Choose TKIP/AES to ensure compatibility with older wireless
devices that may not support AES.
• AES—This option is more secure.
STEP 6 In the RADIUS Server field, enter the IP address of the RADIUS server.
STEP 7 In the RADIUS Port field, enter the port used to access the RADIUS server.
STEP 8 In the Shared Key field, enter an alphanumeric phrase.
STEP 9 In the Key Renewal field, enter the duration of time (600–7200 seconds) between
key renewals. The default value is 3600.
STEP 10 Click Save to save your settings.
STEP 11 Click Back to go back to the Basic Settings page.
Configuring MAC Filtering
You can use MAC Filtering to permit or deny access to the wireless network based
on the MAC (hardware) address of the requesting device. For example, you can
enter the MAC addresses of a set of computers and only allow those computers to
access the network. You can configure MAC Filtering for each network or SSID.
To configure MAC filtering:
STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network
you want to configure.
STEP 2 Click Edit MAC Filtering. The Wireless MAC Filter page appears.
STEP 3 In the Edit MAC Filtering field, check the Enable box to enable MAC Filtering for
this SSID.
STEP 4 In the Connection Control field, choose the type of access to the wireless
network:
• Prevent—Select this option to prevent devices with the MAC addresses
listed in the MAC Address Table from accessing the wireless network. This
option is selected by default.
• Permit—Select this option to allow devices with the MAC addresses listed
in the MAC Address Table to access the wireless network.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
