Cisco RV215W Administration Guide

Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 72
7
Configuring the Security Mode
You can configure one of the following security modes for wireless networks.
Configuring WEP
The WEP security mode offers weak security with a basic encryption method that
is not as secure as WPA. WEP may be required if your network devices do not
support WPA.
NOTE If you do not have to use WEP, we recommend that you use WPA2. If you are using
the Wireless-N only mode, you must use WPA2.
To configure the WEP security mode:
STEP 1 In the Wireless Table (Wireless > Basic Settings), check the box for the network
that you want to configure.
STEP 2 Click Edit Security Mode.
The Security Settings page appears.
STEP 3 In the Select SSID field, choose the SSID for which to configure the security
settings.
STEP 4 From the Security Mode menu, choose WEP.
STEP 5 In the Authentication Type field, choose one of the following options:
• Open System—This is the default option.
• Shared Key—Select this option if your network administrator recommends
this setting. If you are unsure, select the default option.
In both cases, the wireless client must provide the correct shared key (password)
to access the wireless network.
STEP 6 In the Encryption field, choose the encryption type:
• 10/64-bit(10 hex digits)—Provides a 40-bit key.
• 26/128-bit(26 hex digits)—Provides a a 104-bit key, which offers stronger
encryption, making the key more difficult to decode. We recommend 128-bit
encryption.
STEP 7 (Optional) In the Passphrase field, enter an alphanumeric phrase (longer than eight
characters for optimal security) and click Generate Key to generate four unique
WEP keys in the WEP Key fields.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
