Cisco RV215W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV215W Wireless-N VPN Firewall Administration Guide 58
6
STEP 3 Click Save or continue to configure IPv6 DHCP LAN settings.
STEP 4 Enter the following information to configure the DHCPv6 settings:
STEP 5 Choose Networking > IPv6 > IPv6 LAN Configuration.
STEP 6 In the IPv6 Address Pools Table, click Add Row.
IPv6 Prefix Length Enter the IPv6 prefix length.
The IPv6 network (subnet) is identified by the initial
bits of the address called the prefix. By default, the
prefix is 64 bits long.
All hosts in the network have the identical initial bits
for their IPv6 address; you set the number of
common initial bits in the network addresses in this
field.
DHCP Status Check to enable the DHCPv6 server.
When enabled, the device assigns an IP address
within a specified range and provides additional
information to any LAN endpoint that requests
DHCP addresses.
Domain Name (Optional) Domain name of the DHCPv6 server.
Server Preference Server preference level of this DHCP server. DHCP
advertise messages with the highest server
preference value to a LAN host are preferred over
other DHCP server advertise messages.
The default is 255.
Static DNS 1 IPv6 address of the primary DNS server on the ISP
IPv6 network.
Static DNS 2 IPv6 address of the secondary DNS server on the
ISP IPv6 network.
Client Lease Time Client lease time duration (in seconds) for which
IPv6 addresses are leased to endpoints on the
LAN.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
