Cisco RV215W Administration Guide

Configuring Networking
Configuring the LAN Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 41
6
To create a VLAN:
STEP 1 Choose Networking > LAN > VLAN Membership.
STEP 2 Click Add Row.
STEP 3 Enter this information:
STEP 4 Click Save.
To edit the settings of a VLAN, select the VLAN and click Edit. To delete a selected
VLAN, click Delete. Click Save to apply changes.
VLAN ID Numerical VLAN ID to assign to endpoints in the VLAN
membership. The number you enter must be between
3 to 4094. VLAN ID 1 is reserved for the default VLAN,
and is used for untagged frames received on the
interface.
Description A description that identifies the VLAN.
Inter VLAN Routing Allows an end station in one VLAN to communicate
with an end station in another VLAN.
Port 1
Port 2
Port 3
Port 4
You can associate VLANS on the device to the LAN
ports on the device. By default, all LAN ports belong to
VLAN1. You can edit these ports to associate them
with other VLANS. Choose the outgoing frame type for
each port:
Untagged—The interface is an untagged member of
the VLAN. Frames of the VLAN are sent untagged to
the port VLAN.
Tagged—The port is a tagged member of the VLAN.
Frames of the VLAN are sent tagged to the port VLAN.
Excluded—The port is currently not a member of the
VLAN. This is the default for all the ports when the
VLAN is first created.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
