Cisco RV215W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV215W Wireless-N VPN Firewall Administration Guide 54
6
To configure the device to be a DHCPv6 client:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 In the WAN Connection Type field, select Automatic Configuration-DHCPv6.
STEP 3 Click Save.
Configuring a Static IPv6 WAN Address
If your ISP assigns you a fixed address to access the WAN, configure the device to
use a static IPv6 address.
To configure a static IPv6 WAN address:
STEP 1 Choose Networking > IPv6 > IPv6 WAN Configuration.
STEP 2 From the WAN Connection Type menu, select Static IPv6.
STEP 3 Enter this information:
STEP 4 Click Save.
IPv6 Address IPv6 address of the WAN port.
IPv6 Prefix Length Length of the IPv6 prefix (typically defined by the
ISP). The IPv6 network (subnet) is identified by the
initial bits of the address called the prefix. All hosts
in the subnetwork have the identical prefix.
For example, in the IPv6 address
2001:0DB8:AC10:FE01:: the prefix is 2001.
Default IPv6 Gateway IPv6 address of the default gateway. This is
typically the IP address of the server at the ISP.
Static DNS 1 IP address of the primary IPv6 DNS server.
Static DNS 2 IP address of the secondary IPv6 DNS server.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
