Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 70
7
STEP 4 If you chose B/G/N-Mixed, N-Only, or G/N Mixed, in the Wireless Band Selection
field, select the wireless bandwidth on your network (20MHz or 20/40MHz). If
you chose N-Only, you must use WPA2 security on your network. See Configuring
the Security Mode.
STEP 5 In the Wireless Channel field, choose the wireless channel from the drop-down
menu.
STEP 6 In the AP Management VLAN field, choose VLAN 1 if you are using the default
settings.
If you create additional VLANs, choose a value that corresponds with the VLAN
configured on other switches in the network. This is done for security purposes.
You might need to change the management VLAN to limit access to the device
Device Manager.
STEP 7 (Optional) In the U-APSD (WMM Power Save) field, check Enable to enable the
Unscheduled Automatic Power Save Delivery (U-APSD) feature, also referred to as
WMM Power Save, that allows the radio to conserve power.
U-APSD is a power-saving scheme optimized for real-time applications, such as
VoIP, transferring full-duplex data over WLAN. By classifying outgoing IP traffic as
Voice data, these types of applications can increase battery life by approximately
25% and minimize transmit delays.
STEP 8 (Optional) Configure the settings of the four wireless networks (see Editing the
Wireless Network Settings).
STEP 9 Click Save.
B/G-Mixed Choose this option if you have Wireless-B and
Wireless-G devices in your network.
G/N-Mixed Choose this option if you have Wireless-G and
Wireless-N devices in your network.
