Cisco RV215W Administration Guide

Configuring the Wireless Network
Configuring Basic Wireless Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 77
7
• The guest network is configured as one of the four available SSIDs on the
device.
• The guest network cannot be configured on the AP Management VLAN
(VLAN ID 1).
To configure the guest network:
Create a New VLAN
STEP 1 In the Management Interface, choose Networking > LAN > VLAN Membership.
STEP 2 In the VLAN Setting Table, add a new VLAN for the guest network. For example,
click Add Row and enter the following:
• VLAN ID—Enter a number for the VLAN (for example, 4).
• Description—Enter a name for the VLAN (for example, guest-net).
STEP 3 Leave the ports as tagged and click Save.
Set Up the Guest Network
STEP 1 In the Management Interface, choose Wireless > Basic Settings.
STEP 2 In the Wireless Table, choose the SSID or network that you want to designate as
the guest network.
STEP 3 Click Edit. Change the SSID name to reflect the guest designation (for example,
guest-net ).
STEP 4 Check the SSID Broadcast box so that the network will appear as an available
wireless connection to clients searching for networks.
STEP 5 Check the Guest Network box to configure this SSID as the guest network.
STEP 6 Choose the VLAN you created for the guest network (or, if you have not yet
created a network, select Add New VLAN).
STEP 7 Click Save. The system notifies you that the physical Ethernet ports on the device
are excluded from the VLAN that you have assigned to the guest network. In
addition, Wireless Isolation with SSID and WMM are automatically enabled.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
