Cisco RV215W Administration Guide

Configuring the Firewall
Configuring Basic Firewall Settings
Cisco RV215W Wireless-N VPN Firewall Administration Guide 87
8
Block Cookies Check to block cookies. Cookies are used to store
session information by websites that usually
require login. However, several websites use
cookies to store tracking information and browsing
habits. Enabling this option filters out cookies from
being created by a website.
Many websites require that cookies be accepted in
order for the site to be accessed properly. Blocking
cookies can cause many websites to not function
properly.
Click Auto to automatically block cookies, or click
Manual and enter a specific port on which to block
cookies.
Block ActiveX Check to block ActiveX content. Similar to Java
applets, ActiveX controls are installed on a
Windows computer while running Internet Explorer.
A malicious ActiveX control can be used to
compromise or infect computers.
Enabling this setting blocks ActiveX applets from
being downloaded.
Click Auto to automatically block ActiveX, or click
Manual and enter a specific port on which to block
ActiveX.
Block Proxy Check to block proxy servers. A proxy server (or
proxy) allows computers to route connections to
other computers through the proxy, thus
circumventing certain firewall rules.
For example, if connections to a specific IP address
are blocked by a firewall rule, the requests can be
routed through a proxy that is not blocked by the
rule, rendering the restriction ineffective. Enabling
this feature blocks proxy servers.
Click Auto to automatically block proxy servers, or
click Manual and enter a specific port on which to
block proxy servers.

Cisco RV215W Specifications

General

VPN support	3DES, PPTP, L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q
VPN tunnels quantity	6
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Input current	1.67 A
Supported protocols	PPPoE, PPTP, L2TP, RSTP, NAT, DynDNS, PAT, DMZ
Security algorithms	WEP, WPA, WPA2, WPS
Antennas quantity	2
Certification	FCC Class B, CE, IC, UL, cUL, Wi-Fi, C-Tick
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black

Weight and Dimensions

Width	150 mm
Height	30 mm
Weight	300 g
