Administration: Discovery
Discover - LLDP
138 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
9
NOTE The following fields must be entered in hexadecimal characters in the exact data
format that is defined in the LLDP-MED standard (ANSI-TIA-
1057_final_for_publication.pdf):
- Location Coordinate—Enter the coordinate location to be published by LLDP.
- Location Civic Address—Enter the civic address to be published by LLDP.
- Location ECS ELIN—Enter the Emergency Call Service (ECS) ELIN location to
be published by LLDP.
STEP 5 Click Apply. The LLDP MED port settings are written to the Running Configuration file.
LLDP Port Status
The LLDP Port Status page contains the LLDP global information for every port.
STEP 1 To view the LLDP port status, click Administration > Discovery - LLDP > LLDP Port
Status.
Information for all ports , including the OOB port is displayed.
STEP 2 Select a specific port and click LLDP Local Information Detail to see the details of the
LLDP and LLDP-MED TLVs sent out to the port.
STEP 3 Select a specific port and click LLDP Neighbor Information Detail to see the details of the
LLDP and LLDP-MED TLVs received from the port.
• LLDP Port Status Global Information
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the
MAC address of the device appears.
• System Name—Name of device.
• System Description—Description of the device (in alpha-numeric format).
• Supported System Capabilities—Primary functions of the device, such as Bridge,
WLAN AP, or Router.
• Enabled System Capabilities—Primary enabled function(s) of the device.
• Port ID Subtype—Type of the port identifier that is shown.
• LLDP Port Status Table
