Cisco SG350-10MP Administration Guide

Security
RADIUS
328 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
17
• Secret Key—Address of switch containing RADIUS client.
- Use default key—For specified servers, the device attempts to authenticate the
RADIUS client by using the existing, default Key String.
- Encrypted—To encrypt communications by using MD5, enter the key in encrypted
form.
- Plaintext—Enter the key string in plaintext mode.
STEP 5 Click Apply. The key for the device is updated in the Running Configuration file.
RADIUS Server Groups
To set up a group of users that will be using the device as its RADIUS server:
STEP 1 Click Security > RADIUS Server > RADIUS Server Groups.
STEP 2 Click Add and enter the following fields:
• Group Name—Enter a name for the group.
• Privilege Level—Enter the management access privilege level of the group.
• Time Range—Check to enable applying a time range to this group.
• Time Range Name—If Time Range is selected, select the time range to be used. Click
Edit to define a time range in the Time Range section. This field is only displayed if a
Time Range was previously created.
• VLAN—Select the VLAN for the users:
- None—No VLAN ID is sent.
- VLAN ID—VLAN ID sent.
- VLAN Name—VLAN name sent
STEP 3 Click Apply. The RADIUS group definition is added to the Running Configuration file of the
device.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
