Cisco SG350-10MP Administration Guide

Security
RADIUS
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 329
17
RADIUS Server Users
To add a user:
STEP 1 Click Security > RADIUS Server > RADIUS Server Users.
The current users are displayed.
STEP 2 Click Add.
• User Name—Enter the name of a user.
• Group Name—Select a previously-defined group.
• Password—Enter one of the following options:
- Encrypted—A key string is used to encrypt communications by using MD5. To use
encryption, enter the key in encrypted form.
- Plaintext—If you do not have an encrypted key string (from another device), enter
the key string in plaintext mode. The encrypted key string is generated and
displayed
STEP 3 Click Apply. The user definition is added to the Running Configuration file of the device.
RADIUS Server Accounting
The Radius server saves the last accounting logs in a cycle file on FLASH. These can be
displayed.
To display RADIUS server accounting:
STEP 1 Click Security > RADIUS Server > RADIUS Server Accounting.
RADIUS accounting events are displayed along with the following fields:
• User Name—Name of a user.
• Event Type—One of the following values:
- Start—Session was started.
- Stop— Session was stopped.
- Date/Time Change—Date/time on the device was changed.
- Reset—Device has reset at the specified time.
• Authentication Method—Authentication method used by the user. Displays N/A if the
Event Type is Date/Time Change or Reset.

Cisco SG350-10MP Specifications

General

Model	SG350-10MP
Category	Switch
PoE Budget	130W
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power Supply	Internal
Ports	8 x 10/100/1000 PoE+ + 2 x Gigabit SFP
MAC Address Table Size	16K
Jumbo Frame Support	9216 bytes
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Operating Humidity	10% to 90% relative humidity, non-condensing
Storage Humidity	5% to 95% relative humidity, non-condensing
Dimensions (W x D x H)	279.4 x 170 x 44 mm (11.0 x 6.7 x 1.73 in)
