Configuring Dial Plans
About Dial Plans
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 203
8
Digit Sequence Function
0 1 2 3 4 5 6 7 8 9 0
* #
Enter any of these characters to represent a key that
the user must press on the phone keypad.
x
Enter x to represent any character on the phone
keypad.
[sequence]
Enter characters within square brackets to create a list
of accepted key presses. The user can press any one
of the keys in the list.
• Numeric range
For example, you would enter
[2-9] to allow the
user to press any one digit from 2 through 9.
• Numeric range with other characters
For example, you would enter
[35-8*] to allow
the user to press 3, 5, 6, 7, 8, or *.
.
(period)
Enter a period for element repetition. The dial plan
accepts 0 or more entries of the digit. For example,
01. allows users to enter 0, 01, 011, 0111, and so on.
<dialed:substituted>
For sequence substitution, use this format to indicate
that certain dialed digits are replaced by other
characters when the sequence is transmitted. The
dialed digits can be zero or more characters.
EXAMPLE 1:
<8:1650>xxxxxxx
When the user presses 8 followed by a seven-digit
number, the system automatically replaces the dialed 8
with 1650. If the user dials 85550112, the system
transmits 16505550112.
EXAMPLE 2:
<:1>xxxxxxxxxx
In this example, no digits are replaced. When the user
enters a 10-digit string of numbers, the number 1 is
added at the beginning of the sequence. If the user
dials 9725550112, the system transmits
19725550112
