Cisco Small Business SPA509G - Line;Call Status

Cisco SPA IP Phone Field Reference
Info Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 235
B
Line/Call Status
The following parameters show for each line and call on the phone.
Last Registration At Last date and time the line was registered.
Next Registration In Number of seconds before the next registration
renewal.
Message Waiting Indicates whether the phone user has a new voice mail
waiting: Yes or No. This is updated when voice mail
notification is received.
Mapped SIP Port Port number of the SIP port mapped by NAT.
Parameter Description
Parameter Description
Call State Status of the call.
Tone Type of tone used by the call.
Encoder Codec used for encoding.
Decoder Codec used for decoding.
Type Direction of the call.
Remote Hold Indicates whether the far end has placed the call on
hold.
Callback Indicates whether the call was triggered by a call back
request.
Peer Name Name of the internal phone.
Peer Phone Phone number of the internal phone.
Duration Duration of the call.
Packets Sent Number of packets sent.
Packets Recv Number of packets received.
Bytes Sent Number of bytes sent.
