Configuring Lines and Extensions
Configuring Lines
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 41
2
Configuring Unused Line Keys for Call Park on the Cisco
SPA525G/525G2 (MetaSwitch)
You can configure unused line keys for call park (for the MetaSwitch softswitch) on
the Cisco SPA525G/525G2. Users can then press this line button to park a call or
retrieve a parked call. To configure:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login.
STEP 3 Click advanced.
STEP 4 Click the Attendant Console tab. In the General section, under Server Type ,
choose RFC3265_4236.
STEP 5 Click the Phone tab.
STEP 6 Choose the line key to configure (line 5 in this example):
a. From the
Extension drop down list, choose Disabled.
b. From the
Share Call Appearance drop-down list, choose private.
c. Enter the following string in the Extended Function field:
fnc=prk;sub=05@domain.com
where:
- fnc: function
- prk: call park
- sub: call park orbit, or location where the call is parked. Valid value range
is from 01 through 10. In this example, 5 is used.
- domain.com: phone domain, usually the same as the “proxy” value in the
Ext 1 tab. You can also use fnc=prk;sub=05@$PROXY to use this value.
STEP 7 Click Submit All Changes.
Configuring Audio Indication for Call Pickup Event
You can configure the phone to play the Call Pickup tone when there are incoming
calls to any of the lines that the user is monitoring with the Call Pickup function.
