Cisco vEdge Series User Manual

1. Verify the internal dimensions of the rack with a tape measure. The rack-mount tray is 440 mm wide and
must fit within the mounting posts.
2. Have one person grasp both sides of the rack-mount tray on which you secured the vEdge router(s) and
position it in the rack.
Figure 11: Holding the Rack-Mount Tray with the vEdge Router(s) in Place
1. Have a second person secure the rack-mount tray to the two front posts of the rack using four rack-mount
screws provided in the rack-mount kit. See Figure 12.
Figure 12: Screwing the Rack-Mount Tray to the Two Front Posts of the Rack
Hardware Installation Guide for vEdge Routers
141
vEdge 1000 Router
Install the vEdge 1000 Router

Cisco vEdge Series Specifications

General

Connectivity Technology	Wired
Virtualization Support	Yes
High Availability	Yes
QoS Support	Yes
Product Type	Router
Data Link Protocol	Ethernet
Routing Protocols	BGP, OSPF
Interfaces	Gigabit Ethernet
Operating System	Cisco vEdge OS
Security	IPSec
Management	CLI
