Management Port
The management port on a vEdge 2000 router uses an RJ-45 connector to connect to a management device
for out-of-band management.
The management port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T connection. The
two LEDs on the port indicate link/activity on the port and the administrative status of the port. See Management
Port LEDs below.
Table 4 provides the pinout information for the RJ-45 connector for the management port.
Table 62:
DescriptionSignalPin
Transmit/receive data pair
1
TRP1+1
Transmit/receive data pair
1
TRP1-2
Transmit/receive data pair
2
TRP2+3
Transmit/receive data pair
3
TRP3+4
Transmit/receive data pair
3
TRP3-5
Transmit/receive data pair
2
TRP2-6
Transmit/receive data pair
4
TRP4+7
Transmit/receive data pair
4
TRP4-8
Management Port LEDs
The management port on the vEdge 2000 router has two LEDs that indicate link/activity and port status. See
Figure 4.
Figure 4: LEDs on the Management Port on a vEdge 2000 Router
Hardware Installation Guide for vEdge Routers
177
vEdge 2000 Router
Ports and Connectors
