12-25
Catalyst 3560 Switch Software Configuration Guide
78-16156-01
Chapter 12 Configuring VLANs
Configuring VLAN Trunks
Beginning in privileged EXEC mode, follow these steps to configure the network shown in Figure 12-3.
Command Purpose
Step 1
configure terminal Enter global configuration mode on Switch A.
Step 2
vtp domain domain-name Configure a VTP administrative domain.
The domain name can be from 1 to 32 characters.
Step 3
vtp mode server Configure Switch A as the VTP server.
Step 4
end Return to privileged EXEC mode.
Step 5
show vtp status Verify the VTP configuration on both Switch A and Switch B.
In the display, check the VTP Operating Mode and the VTP Domain
Name fields.
Step 6
show vlan Verify that the VLANs exist in the database on Switch A.
Step 7
configure terminal Enter global configuration mode.
Step 8
interface gigabitethernet 0/1 Enter interface configuration mode, and define the interface to be
configured as a trunk.
Step 9
switchport trunk encapsulation {isl |
dot1q | negotiate}
Configure the port to support ISL or 802.1Q encapsulation or to
negotiate with the neighboring interface. You must configure each
end of the link with the same encapsulation type.
Step 10
switchport mode trunk Configure the port as a trunk port.
Step 11
end Return to privileged EXEC mode.
Step 12
show interfaces gigabitethernet 0/1
switchport
Verify the VLAN configuration.
Step 13
Repeat Steps 7 through 11 on Switch A for a second interface in the
switch.
Step 14
Repeat Steps 7 through 11 on Switch B to configure the trunk ports
that connect to the trunk ports configured on Switch A.
Step 15
show vlan When the trunk links come up, VTP passes the VTP and VLAN
information to Switch B. Verify that Switch B has learned the VLAN
configuration.
Step 16
configure terminal Enter global configuration mode on Switch A.
Step 17
interface gigabitethernet 0/1 Enter interface configuration mode, and define the interface to set the
STP port priority.
Step 18
spanning-tree vlan 8-10 port-priority 16 Assign the port priority of 10 for VLANs 8 through 10.
Step 19
exit Return to global configuration mode.
Step 20
interface gigabitethernet0/2 Enter interface configuration mode, and define the interface to set the
STP port priority.
Step 21
spanning-tree vlan 3-6 port-priority 16 Assign the port priority of 10 for VLANs 3 through 6.
Step 22
end Return to privileged EXEC mode.
Step 23
show running-config Verify your entries.
Step 24
copy running-config startup-config (Optional) Save your entries in the configuration file.
