26-12
Catalyst 3560 Switch Software Configuration Guide
78-16156-01
Chapter 26 Configuring SNMP
Configuring SNMP
Note Though visible in the command-line help string, the fru-ctrl and flash insertion and removal keywords
are not supported.
You can use the snmp-server host global configuration command to a specific host to receive the
notification types listed in Table 26-5.
Table 26-5 Switch Notification Types
Notification Type
Keyword Description
bgp Generates BGP state change traps. This option is only available when the
enhanced multilayer image is installed.
bridge Generates STP bridge MIB traps.
cluster Generates a trap when the cluster configuration changes.
config Generates a trap for SNMP configuration changes.
config-copy Generates a trap for SNMP copy configuration changes.
entity Generates a trap for SNMP entity changes.
envmon Generates environmental monitor traps. You can enable any or all of these
environmental traps: fan, shutdown, supply, temperature.
flash Generates SNMP FLASH notifications.
hsrp Generates a trap for Hot Standby Router Protocol (HSRP) changes.
mac-notification Generates a trap for MAC address notifications.
port-security Generates SNMP port security traps. You can also set a maximum trap rate
per second. The range is from 0 to 1000; the default is 0, which means that
there is no rate limit.
rtr Generates a trap for the SNMP Response Time Reporter (RTR).
snmp Generates a trap for SNMP-type notifications for authentication, cold start,
warm start, link up or link down.
stpx Generates SNMP STP Extended MIB traps.
syslog Generates SNMP syslog traps.
tty Generates a trap for TCP connections.
vlan-membership Generates a trap for SNMP VLAN membership changes.
vlancreate Generates SNMP VLAN created traps.
vlandelete Generates SNMP VLAN deleted traps.
vtp Generates a trap for VLAN Trunking Protocol (VTP) changes.
