27-12
Catalyst 3560 Switch Software Configuration Guide
78-16156-01
Chapter 27 Configuring Network Security with ACLs
Configuring IP ACLs
or access-list access-list-number
{deny | permit} protocol any any
[precedence precedence] [tos tos]
[fragments] [log] [log-input]
[time-range time-range-name]
[dscp dscp]
In access-list configuration mode, define an extended IP access list using an
abbreviation for a source and source wildcard of 0.0.0.0 255.255.255.255 and
an abbreviation for a destination and destination wildcard of 0.0.0.0
255.255.255.255.
You can use the any keyword in place of source and destination address and
wildcard.
or access-list access-list-number
{deny | permit} protocol
host source host destination
[precedence precedence] [tos tos]
[fragments] [log] [log-input]
[time-range time-range-name]
[dscp dscp]
Define an extended IP access list using an abbreviation for a source and source
wildcard of source 0.0.0.0 and an abbreviation for a destination and destination
wildcard of destination 0.0.0.0.
You can use the host keyword in place of source and destination wildcard
or mask.
Step 2b
access-list access-list-number
{deny | permit} tcp source
source-wildcard [operator port]
destination destination-wildcard
[operator port] [established]
[precedence precedence] [tos tos]
[fragments] [log] [log-input]
[time-range time-range-name]
[dscp dscp] [flag]
(Optional) Define an extended TCP access list and the access conditions.
Enter tcp for Transmission Control Protocol.
The parameters are the same as those described in Step 2a with these exceptions:
(Optional) Enter an operator and port to compare source (if positioned after
source source-wildcard) or destination (if positioned after destination
destination-wildcard) port. Possible operators include eq (equal), gt (greater
than), lt (less than), neq (not equal), and range (inclusive range). Operators
require a port number (range requires two port numbers separated by a space).
Enter the port number as a decimal number (from 0 to 65535) or the name of a
TCP port. To see TCP port names, use the ? or refer to “Configuring IP Services”
section of Cisco IOS IP and IP Routing Command Reference for IOS Release
12.1. Use only TCP port numbers or names when filtering TCP.
The additional optional keywords have these meanings:
• established—Enter to match an established connection. This has the same
function as matching on the ack or rst flag.
• flag—Enter one of these flags to match by the specified TCP header bits:
ack (acknowledge), fin (finish), psh (push), rst (reset), syn (synchronize),
or urg (urgent).
Step 2c
access-list access-list-number
{deny | permit} udp
source source-wildcard [operator
port] destination
destination-wildcard [operator
port] [precedence precedence]
[tos tos] [fragments] [log]
[log-input] [time-range
time-range-name] [dscp dscp]
(Optional) Define an extended UDP access list and the access conditions.
Enter udp for the User Datagram Protocol.
The UDP parameters are the same as those described for TCP except that
[operator [port]] port number or name must be a UDP port number or name, and
the flag and established parameters are not valid for UDP.
Command Purpose
