FreeSpeak II for Eclipse | User Guide
The E-IPA card enables up to 64 FS II connections (according to license) which may be made
up of any combination of:
l
FS II IP Transceivers (up to 64)
l
FS II beltpacks (up to 64)
Radio Frequency
(RF) Band
Minimum number. of
transceivers in one RF cell
Maximum number of beltpacks
supported in one RF cell
1.9 GHz BV32
codec
1 8 - 10
2 16 - 20
3 24 - 30
4 32 - 40
2.4 GHz Not supported Not supported
Note: The IP Transceiver supports up to 10 beltpacks, but to enable effective roaming Clear-Com
recommends eight beltpacks per transceiver.
Page 14
