FreeSpeak II for Eclipse | User Guide
3. Select the Wireless radio button.
4. Select Next, and then browse to the upgrade file (.tar.gz) and select Open. The upgrade file
is loaded to the transceiver, and the transceiver restarts.
You can track the status of the download in the EHX Event Log.
6.14 Upgrading by USB connection
Place the *tar.gz upgrade image onto a USB stick in a folder named firmware_upgrade located
in the root of the USB FAT32 file system.
Note: Make sure that there is only one upgrade image in the folder. If not, the incorrect image
might be upgraded.
The upgrade will begin automatically when you insert the USB stick.
Note: Both status LEDs will flash light blue once per second for 5 seconds on successful
detection of the upgrade file. Both status LEDs will light solid red if there is an error
duing the upgrade.
6.15 Port security settings
The following port security settings apply for the IP Transceiver.
Note: All ports are closed by default, and the firewall is enabled.
Port Setting
AES67 Admin
DHCP (67, 68)
mDNS (5553)
HTTP (80, 8080, 443)
rsync (873)
IVP port is configurable
AES67 Audio
DHCP (67, 68)
PTP (319, 320)
mDNS (5353)
IVP (6001)
HTTP (8080)
6.16 Network and synchronization
l
The transceiver is shipped with DHCP enabled (default). The transceiver supports static
IP addressing, but if you use a static IP you will need to enter two static IP addresses.
Page 75
