Transceiver state Status LED (LED 1 shows normal operating mode)
Power on test failure LED 2 red 2 Hz
Temperature
LED 1 red 2 Hz: overheat. LED 1 light blue 2 Hz:
underheat
No data connection LED 1 white 2 Hz
Initializing AES67/locking to
PTP
LED 1 purple 2 Hz
Acquiring DECT sync LED 1 amber 2 Hz
Transceiver online and ready for
beltpack connection
LED 1 solid amber
Standalone (rigging) mode
LED 2 double flash amber: device is in Standalone mode.
LED 1: normal indication, solid amber: standalone
transceiver is online and ready for beltpacks
LED 1 and 2 solid amber: device has entered standalone
mode, release mode button.
Mode indicators (LED 2)
Press and hold the Mode button:
>3 secs: LED 2 white (state 1)
>6 secs: LED 2 green (state 2)
>9 secs: LED 2 amber (state 3)
>12 secs:LED 2 red (state 4)
Press and hold the Mode button until LED 2 is red to reset
device to default (DHCP).
6.4 IP Transceiver fans and filters
The IPT operating temperature is 0 to 45 C in shaded conditions.
Each transceiver contains two fans which activate when the IPT internal temperature reaches
55 C. If the internal temperature reaches 60 C, LED 1 will flash red at 2 Hz.
You should periodically check that the fans function correctly, and if necessary replace them.
Note: If a fan fails, LED 1 flashes red at 4 Hz.
Each transceiver contains two internal filters and one external filter to protect the device from
dust and other atmospheric debris.
You should periodically clean the filters with warm water and let them dry. Replace them if they
are damaged.
Page 59
