Page 22 BB4500-BB5000 Operating Manual
Both motors have a four-speed gearbox for maximum versatility. Table 2-10 speci-
fies the operating range for each gear.
CAUTION
Before shifting gears, remove the cutting load from the motor and stop
the motor rotation. Shifting gears while the machine is under load could
damage the motor and gearbox components.
CLIMAX’s portable machine tools require a three-wire extension cord. Extension
cords of inadequate wire size may cause a significant drop in mains voltage with a
consequent loss of power.
As the distance from the supply outlet increases, heavier gauge extension cords are
required (see Table 2-11).
TABLE 2-9. POWER RATING
120V motor:
3.35 hp (2.5 kW)
20 Amps 60 Hz
230V motor:
3.35 hp (2.5 kW)
10.5 Amps 60 Hz
TABLE 2-10. SPEED RANGE AND TORQUE PER GEAR
Gear Knobs RPM range
Rated bar
speed
Bar torque
1
● ●
8.0–23.0 RPM 20 RPM 470 ft-lb (637 Nm)
2
● ●●
12.5–35.5 RPM 30 RPM 300 ft-lb (407 Nm)
3
●● ●
35.5–101.0 RPM 90 RPM 105 ft-lb (142 Nm)
4
●● ●●
56.5–160.0 RPM 142.5 RPM 65 ft-lb (88 Nm)
TABLE 2-11. RECOMMENDED WIRE GAUGE FOR EXTENSION CORDS
Cord length
25 feet
(7.6 m)
50 feet
(15.2 m)
75 feet
(22.9 m)
100 feet
(30.5 m)
150 feet
(45.7 m)
200 feet
(61 m)
Nameplate amps Minimum wire gauge
0–5.0 16 16 16 14 12 12
5.1–8.0 16 16 14 12 10
8.1–12.0 14 14 12 10
12.1–15.0 12 12 10 10
15.1–20.0 10 10 10
