P/N 92974, Rev. 1 Page 23

Table 2-12 and Table 2-13 list the service parts for both motors.

TABLE 2-12. 120V SERVICE PARTS

Part number Description Quantity

83595 Rotor complete 1

82698 Carbon brush 2

83593 PCB / circuit board 1

83594 Stator complete 1

TABLE 2-13. 230V SERVICE PARTS

Part number Description Quantity

90776 Rotor Complete 1

90778 Brush Holder 2

85088 Carbon Brush 2

83591 Anti Parasite Condenser 1

85089 PCB / Circuit Board 1

82699 Cap 1

90779 Stator Complete 1

83601 Grooved Ball Bearing 6201 LUZ 1

90780 Locking Ring 32x1,2 1

83602 Shaft Seal Ring 15x21x3 KEIV 1

90238 Work Spindle 1

90781 Shaft Seal Ring 30x42x7 1

90782 Grooved Ball Bearing 6005 2RS 1

90783 O-ring 106x2 1

85494 Switch Button Long 1

85493 Switch Button Short 1

90784 Connector Socket 1

90785 Insert 1

90786 Screw 3x10 4

87279 Reversing switch 1

90787 Connector Pin 2,5 mm2 3

90788 Connector Pin 0.75 mm2 2
