InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
3.1 IM-NT Installation instructions
This portion of Instalation instructions is dedicated to the
InteliMains-NT-GC controller with built-in display. If you have
BaseBox type of the controller (without the built-in display), please
refer to the section 3.2.
3.1.1 Mounting
Prepare the screw holders
Locate four sockets for screw holders
Insert the unit into cut-out in a switchboard and
insert all four screw holders accordingly to their
positions
Tighten as required to fix the controller in the
position
