Technical Data
Inputs/Outputs overview
Model
BIN
BOUT
COM1
COM2
Gen.
Voltage
Mains
Voltage
Gen.
Current
IA-NT PWR
7
7
Y*
Y*
Y
Y
Y
NOTE:
* With optional plug-in module
Y – Available
N – Not available
Power supply
Voltage supply 8–36V DC
Consumption 40–430mA depend on supply voltage and
temperature
Consumption depends on supply voltage 0.104A at 8VDC
0.080A at 12VDC
0.051A at 24VDC
0.044A at 30VDC
0.040A at 36VDC
Allowed supply voltage drop-out: 100ms from min. 10V, return to min. 8V
Battery voltage measurement tolerance 2 % at 24V
NOTE:
For the supply voltage less than 7V the backlight of the display is switched off.
Short-term voltage drops (e.g. during the engine cranking) do not affect the operation at all.
Operating conditions
Operating temperature IA-NT -20..+70
o
C
Storage temperature -30..+80
o
C
Protection front panel IP65
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 61000-6-3:2006, EN 61000-6-3:2006
EN 61000-6-1:2005, EN 61000-6-2:1999
Vibration 2 – 25 Hz, ±1.6 mm
25 – 100 Hz, a = 4 g
Shocks a = 500 m/s
2
EMC environment conditions classification according to standard 60947-6-1: Type A (industrial
equipment)
Dimensions and weight
Dimensions 180x120x55mm
Weight 450g
